Earthing system projects 4.0

We have a technical team of experts and the most advanced software to carry out any earthing project, meeting the most advanced requirements such as in Industry 4.0, Smart City projects, Smart Grids projects or digital transformation projects.

  1. Aplicaciones Tecnológicas
  2. /
  3. Smart Earthing
  4. /
  5. Earthing system projects 4.0
null

The efficiency, safety and reliability of an earthing system start with a good project

After the initial evaluation of the project, our software compares the different solutions to the problem, indicating which is the most optimal in terms of cost, technical requirements, noise minimisation, etc.

We provide two types of service: projects 4.0 and premium projects 4.0

Smart technology for the earthing system monitoring

The monitoring of earthing systems allows not only to meet the most advanced requirements such as in Industry 4.0, Smart City projects, Smart Grids projects or digital transformation projects, but also with regulatory periodic checks, supervision of the degradation of critical systems, detection of acts of vandalism, etc., continuously assessing the safety of people and goods. We carry out advanced design projects for earthing systems monitoring.

null
null

Our earthing system projects 4.0 include:

null

Preliminary realization of a geoelectric study to determine the stratification and soil resistivity. Aplicaciones Tecnológicas S.A. offers a highly competitive geoelectric study service muy competitivo.

null
null

Designs based on international standards using advanced software that allows us to determine objectively the optimum solution.

null
null

Use of anti-theft conductors and specific electrodes according to the particularities of the terrain: corrosion-resistant electrodes for aggressive soils, special electrodes and/or perimeter ring conductors for highly resistive soils, etc.

null
null

Durable connections between conductors by using Apliweld® exothermic welding, which remain in excellent condition for the entire service life of the installation.

null
null

Advanced and continuous monitoring system of the status of the earthing system using the Smart Earthing Monitoring System.

Projects 4.0 Service

null

The project report in the project 4.0 mode provides the following information:

  • Layout of the suggested design.
  • Calculation of earthing resistance.
  • Verification of compliance with maximum admissible touch and step voltages.
  • List of materials and budget.
  • Smart Earthing Monitoring System

Premium Project 4.0

null

In addition to the information provided in the project 4.0 report, it is possible to include any of the following options:

  • Calculation of short-circuit current to earth.
  • Lightning strike transient analysis.
  • Transient short circuit analysis.
  • Frequency analysis.
  • Interaction analysis between earthing networks.
  • Technical and economical optimisation of the earthing grid.
  • Use of foundation as a part of the earthing system.
  • Analysis of the earth-surge protection interaction.
  • Evaluation of the building’s down conductor system against lightning strikes.

Why to incorporate smart technology in earthing system projects?

null

Prevention of hazards due to step and touch voltages in unsupervised or poorly maintained installations

null

Early detection of asset failures due to malfunctions.

null

Logistic simplification of periodic verification processes

null

Real time alerts for corrective maintenances

null

Predictive maintenance based on data

null

Detection of theft and acts of vandalism

We develop ad-hoc projects according to customer requirements.
