Real-time information improves safety

SMART LIGHTNING LOGGER is a smart system for real-time alert and recording of captured lightning strikes, which is installed in the down conductor of the lightning rod and, using IoT communication, reports the impact and its characteristics at the moment it occurs.

Real-time control of the lightning protection installation allows immediate verification after an impact to check possible damage, without waiting for the next on-site inspection

continuously monitors the activity in the down conductor of the lightning rod, providing information for each lightning strike on its amplitude, polarity, duration, load, specific energy, date and time.

Advantages of the system

Identification and characterization of each lightning strike
null

REAL-TIME LIGHTNING
STRIKE ALERTS

The monitoring of electrical activity on the blades allows alerting at the exact moment of impact and thus facilitates immediate inspections and early repairs, which saves significant costs.

null

CHARACTERISATION
OF THE DISCHARGE

Precise information about the main parameters of the intercepted lightning strike.

null

CONTROL OFMULTIPLE FACILITIES

SMART LIGHTNING LOGGER allows the allows the permanent monitoring of facilities distributed in different locations with centralised data.

SMART LIGHTNING LOGGER
operation

SMART LIGHTNING LOGGER provides real-time lightning strike alerts in a centralised way and through IoT communication for one or multiple facilities.

Each registered data is transferred via IoT communication to the secure and redundant AT-CLOUD data centre where it is processed and transformed into useful information for the user.

null

Data Collection

Continuous monitoring of electrical activity in the down conductors of lightning protection systems where SMART LIGHTNING LOGGER is installed.

null

Accurate diagnostics

Local data is sent to the AT-CLOUD where expert algorithms process it to provide real-time lightning strike alerts and accurate lightning current information.

null

Objective multi-channel alerts

The processed information is sent to the user via the CONNECT platform. This enables immediate inspections (to determine the urgency and type of response), early repairs and analysis in the event of an incident.

null

SMART LIGHTNING LOGGER
System features

Real-time lightning strike alerts

Configurable alert and alarm criteria.

Configurable and remotely operable

User portal and APP, in addition to userdefined channels

Real-time recording and characterisation

  • Amplitude
  • Polarity
  • Duration
  • Load
  • Specific energy
  • Date and time

IoT communication

  • Real-time strike data
  • Weekly life signal and equipment status
  • Self-diagnosis, Battery level, Mobile coverage and Mobile operator
  • Automatic upgrades and updates

Local storage of measurement history

Greater data security

Compact design

A single module including sensor, electronics, IoT communications system and autonomous power supply. No fiber optics or auxiliary nodes.

Robust equipment

With overcurrent and overvoltage limiters that ensure its operability after a lightning strike

Tested according to UNE-EN IEC 62561-6:2018

“Requirements for lightning impact strike counters”

Visualisation platform:
Multi-channel alert system

SMART LIGHTNING LOGGER information is centralised for multi-location customers and is managed from anywhere via multi-channel management solutions (private web portal, mobile devices, SCADA integration, e-mail, sound alarms, etc.)

null

  • Mobile App for visualisation and reception of alarms in real-time.
  • Real-time visualisation of the status of the equipment on a private web portal.
  • Real-time data integration with SCADA systems through various protocols.

  • Alerts indicated by GPS positioning on the map and in a pop-up element accompanied by sound.
  • Generation of PDF reports and downloading of CSV format files for studies and reports by the user.
  • Additional meteorological information: Temperature, Wind Direction and Speed, Barometer, Humidity and Rainfall probability.
